Power Steering Pump: Procedures
Power Steering Pump, Assembly Overview
Power steering pump, assembly overview
Vehicles with 8-cylinder gasoline engine
Note:
^
Replace sealing rings.
^
Do not re-use hydraulic fluid which has been drained off.
^
Hydraulic fluid: Part no. G 002 000
^
On replacing vane pump, always check alignment of belt pulleys of air-conditioner compressor and vane pump.
1. Banjo bolt, 47 Nm
2. Sealing rings, 16 x 22
^
Always replace
3. Pressure hose
4. Suction hose
5. Clamp
^
Tighten with V.A.G 1275 or VAS 6199
^
Always replace
6. Power steering pump
^
Fill with fluid before installing
^
Check delivery pressure
7. Shim
^
Different versions see Parts catalog
8. Belt pulley
9. Hex socket-head bolt, 25 Nm
10. Bolt, 25 Nm
11. Bracket
