Q5 Quattro V6-3.2L (CALB) (2009)
/Page-1083002.png)
-
Remove air grille - 2 - from bumper cover - arrow B -.
-
Remove bolts - 1 - and - 2 - and remove bumper cover noise insulation toward the rear.
-
Remove bolts - arrows - and remove secondary air pump.
‹› The installation location is shown with the bumper cover removed.
