Q7 Quattro V6-3.6L (BHK) (2007)
/Page-8242002.png)
^
Remove the seatbelt covering as shown
^
Remove screw - Torx Tx 30 3.5 NM
^
Remove Cover at shown points; removal direction shown
^
Remove front seat cover by pressing the clips toward the back of the vehicle and lightly pull on the cover. Shown in detailed photo.
-
Use a short or bent screwdriver to release the clips
-
Release the clips in the order shown in the photo.
