Q7 Quattro V6-3.6L (BHK) (2007)
-
Install new locking flange seal dry.
-
Bring right locking flange to installation position.
‹› Tab - 2 - on right locking flange faces toward arrow marking and must lie between tabs - 1 - and - 3 - on fuel tank.
-
Install locking flange cover.
-
Install tank access carpet frame in floor covering.
-
Install right seat frame in 2nd row.
-
Connect battery. Observe safety precautions after connecting battery.
With Auxiliary Heater
-
Allow to run 10 minutes at full throttle to bleed fuel supply line to auxiliary heater metering pump.
