Q7 Quattro V6-3.6L (BHK) (2007)
-
Now, using wood block, press wheel bearing housing down far enough to remove bolt - Arrow -.
-
Remove parking brake.
-
Remove wheel hub and wheel bearing. Refer to => [ Wheel Hub and Wheel Bearing ] See: Wheel Bearing/Service and Repair/Removal and
Replacement/Rear Suspension/Wheel Hub and Wheel Bearing.
-
Remove shield.
-
Remove bolts - 1 - to - 4 -.
-
Remove wheel bearing housing - 5 -.
-
Remove connector from rear speed sensor - 4 -.
-
Remove wiring harness from bracket - 1 -.
‹› Only if wheel bearing housing is to be replaced:
-
Remove screw - 2 - and bracket - 1 -.
-
Remove screw - 3 - and remove rear speed sensor - 4 - from wheel bearing housing.
Installing
Installation is performed in the reverse order of removal. Observe the following when doing so:
-
Install wheel hub and wheel bearing. Refer to => [ Wheel Hub and Wheel Bearing ] See: Wheel Bearing/Service and Repair/Removal and
