Q7 Quattro V6-3.6L (BHK) (2007)
/Page-3709001.png)
Flex Plate: Service and Repair
Drive Plate, Assembly Overview
Drive plate, assembly overview
1 -
Drive plate
2 -
Washer
^
Installed location: Dimple - arrow - faces toward transmission side
3 -
Bolt
^
Replace
^
60 Nm plus an additional 1/4 turn (90°).
4 -
Crankshaft
5 -
Spacer washer
^
Installed location: One hole offset from center
