TT Coupe L4-2.0L Turbo (CCTA) (2008)
Headlamp Washer Motor: Customer Interest
Wipers/Washers - Headlamp Washer System Inoperative
92 Headlight Washer System Does Not Work
92 09 03
2015683/5
June 22, 2009.
Supersedes Technical Service Bulletin Group 92 number 09-01 dated May 13, 2009 for reasons listed below.
Affected vehicles
Condition
The headlight washer system does not function when tested during the pre-delivery inspection.
Technical Background
The headlight washer system circuit fuse, 30 ampere, has been removed by the factory. This is done for transport protection.
-
For TT models, the fuse has been placed in the spare fuse position number 1 of the fuse panel located in the engine compartment (ST1).
-
For A3 models, the fuse has been placed in the spare fuse position number 4 of the fuse panel located under the left side instrument panel (SC).
Production Solution
No change.
Service
Install the fuse during the pre-delivery inspection. Please refer to the fuse panel cover for correct fuse location.
Warranty
This TSB is informational only and not applicable to any Audi warranty.
Additional Information
All parts and service references provided in this TSB are subject to change and/or removal. Always check with your Parts Department and service
manuals for the latest information.
