TT Quattro Coupe L4-1.8L Turbo (AMU) (2001)
/Page-2341001.png)
Brake Switch (Cruise Control): Service and Repair
Cruise control or Interlock switch, removing and installing
Removing
-
Remove trim/driver's side bottom
-
Disconnect connector -1- from interlock switch.
-
Rotate interlock switch -2- in direction of arrow 90° to the left and pull out switch.
The cruise control switch -3- is removed in the same way.
Installing
Installation is the reverse order.
-
Grease plunger head of cruise control i.e. interlock switch with polycarbamide grease, part number G 052 142 A2.
-
The cruise control switch must be installed in the upper mounting hole.
