TT Quattro Coupe L4-1.8L Turbo (AMU) (2001)
/Page-30001.png)
Radiator Cooling Fan Control Module: Locations
A/C Components, Engine Compartment
NOTE:
-
Upon completion of any A/C system repairs, always check and erase the Diagnostic Trouble Code (DTC) memory (scan tool function 02), perform
basic setting (function 04) and code the A/C control head -E87- (function 07).
-
All components marked with an asterisk (*) are activated during output Diagnostic Test Mode (DTM) (function 03).
-
Note different coding possibilities for A/C control head -E87- .
-
Electrical testing can be performed on all components marked with a double asterisk (**).
1
-
Air extraction vents
-
Sealing flaps in vent must move freely and close automatically.
