TT Quattro Coupe V6-3.2L (CBRA) (2008)
/Page-722003.png)
‹› Before tightening, ensure exhaust system is tension-free => [ Exhaust System, Installing ] See: Service and Repair/Removal and Replacement
‹› Installed location, refer to => [ Clamping Sleeve Location ]
‹› Tighten threaded connections evenly.
18
Rear Muffler
‹› Unit with center muffler
‹› Install exhaust system free of stress, refer to => [ Exhaust System, Installing ] See: Service and Repair/Removal and Replacement
19
Retaining Loop
‹› Replace if damaged
20
Nut
‹› 23 Nm
Clamping Sleeve Location
-
Install clamping sleeve in angle position shown.
‹› Threaded connections point toward the right.
‹› Nuts face up.
‹› alpha = approximately 20°
