1 Series E81 116i (N43) 3-door
11 22 500
Removing and installing or replacing flywheel
(N43B16)
Special tools required:
•
11 4 180
•
11 9 260
Necessary preliminary tasks:
•
Clutch removed.
Block flywheel (1) with special tool 11 9 260 .
Release bolts (2) with special tool 11 4 180 .
Tightening torque: 11 22 1AZ
.
Unfasten screws and remove flywheel.
RA Removing and installing or replacing flywheel (N43B16)
