1 Series E81 116i (N43) 3-door
11 23 010
Removing and installing or vibration damper
(N43B16)
Special tools required:
•
11 8 180
Necessary preliminary tasks:
•
Remove alternator drive belt.
Lock flywheel with special tool 11 8 180 .
Release screws (1) and remove vibration damper.
Tightening torque, 11 23 1AZ
.
RA Removing and installing or vibration damper (N43B16)
