1 Series E81 116i (N43) 3-door
34 33 071
Replacing vacuum hose for brake booster
(N43)
Necessary preliminary tasks:
•
Read and comply with General Information.
•
Remove lower section of microfilter housing
•
Remove ignition coil cover
Important!
Before beginning work, fully press the brake pedal several
times to reduce the vacuum pressure in the brake booster.
This makes it easier to detach the vacuum hose.
Unlock quick-release fastener (1) and pull out vacuum line (2).
Unlock quick-connect coupling (1) and detach vacuum line.
Disconnect vacuum hose (2) from vacuum line.
Release vacuum hose at clip (3) and remove.
RA Replacing vacuum hose for brake booster (N43)
