1 Series E81 116i (N43) 3-door
51 43 148
Removing and installing or replacing panel
for left or right door pillar
Release side trim panel (1) at retainers (2) and clip (3).
Release trim panel (5) at clips (4) and remove in downward
direction.
Installation:
If necessary, replace faulty clips (3 and 4).
Complete removal only:
Lever out cap (1).
Release screw (2) and detach seat belt strap.
Tightening torque 72 11 5AZ
.
Feed out seat belt strap from trim for door pillar.
Installation:
Check that spacer bushing (3) and rubber ring (4) are in correct
position.
Installation:
Guides (1) on trim (2) must not be damaged.
