1 Series E81 120d (N47) 3-door
11 12 000
Removing and installing/sealing cylinder head
cover (N47, N47S)
Important!
When working on the oil, coolant or fuel circuit, you must
protect the alternator against contamination.
Cover alternator with suitable materials.
Failure to comply with this procedure may result in an alternator
malfunction.
Necessary preliminary tasks:
•
Remove intake air manifold.
•
Remove all injectors.
•
Release engine wiring harness in area of cylinder head
cover.
Release screws (1).
Lay cable holder (2) to one side.
Release bolts along line (1).
