Removing and Installing Water Pump for BMW 1 Series E81 120d (N47/N47S)
11 51 000
Removing and installing/replacing water
pump (N47, N47S)
Necessary preliminary tasks:
•
Remove alternator driver belt
•
Remove EGR cooler (automatic transmission only)
•
Remove coolant thermostat
Release screws (1) and remove water pump.
Installation:
Replace seal (1).
Assemble engine.
Bleed cooling system and check for leaks.
RA Removing and installing/replacing water pump (N47, N47S)
BMW AG - TIS
19.01.2013 11:50
Issue status (12/2007) Valid only until next DVD is issued
