1 Series E81 123d (N47S) 3-door
33 32 165
Removing and installing or replacing tension
strut
Important!
Observe safety instructions for raising the vehicle
Driving without the tension strut is not permitted!
Release screws (1, 3).
Remove tension strut (2).
Installation:
Tightening torque 33 32 11AZ
(to body).
Tightening torque 33 32 12AZ
(to compression strut).
RA Removing and installing or replacing tension strut
BMW AG - TIS
21.01.2013 14:38
Issue status (12/2007) Valid only until next DVD is issued
