1 Series 120d (N47) Coupe
65 77 720
Removing and installing (replacing) left B-
pillar sensor
Warning!
Note airbag safety instructions!
Incorrect handling can activate airbag and cause injury.
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection)!
Necessary preliminary tasks:
•
Disconnect battery negative lead and cover
•
Remove rear side trim panel
Release screw (1).
Loosen screw (2).
Installation:
Tightening torque 65 77 5AZ
.
Feed out B-pillar sensor and disconnect associated plug
connection.
RA Removing and installing (replacing) left B-pillar sensor
BMW AG - TIS
15.01.2013 23:21
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
