1 Series 128i (N52K) Coupe
Connecting special tool:
Connect special tool 32 4 000 (refer to Notes on use) with new
sealing rings to vane pump and pressure line.
1.
Connection, vane pump
2.
Connection, power steering gear
Checking pump pressure:
1.
Close valve (A).
2.
Open valve (B).
3.
Fill and bleed hydraulic system
4.
Start engine
5.
Heat hydraulic fluid to approx. 50
°
C by moving steering
wheel at increased engine speed.
6.
Close valve (B) for max. 10 secs. and read off pressure.
7.
Compare measured pressure with specified nominal pressure
.
Replace vane pump if the nominal pressure is exceeded by
more than 10 %.
Check belt tension if the nominal pressure is undershot by
more than 10 %. Replace vane pump if belt tension is OK.
After installation:
•
Fill and bleed hydraulic system
•
Check pipe connections for leaks
