1 Series 128i (N52K) Coupe
41 00 ...
Notes on repairing threads
Important!
Install Helicoil thread inserts so that they are flush with the original thread.
Note:
Damaged threads may be repaired with Helicoil thread inserts. Comply with the procedure described in the
example.
Screw/bolt connection
Vehicle
Screw/bolt fastening
point(s)
Helicoil thread insert
Front axle carrier to engine
carrier
E46
All
M12x1.5x18
E53
All
M12x1.5x18
E60, E61, E63, E64
Front, middle
See repair elements
Rear
M12x1.5x18
E65, E66, E67
All
M12x1.5x18
E70, E71
All
M14x1.5x21
E83
All
M12x1.5x18
E85, E86
All
M12x1.5x18
E81, E82, E87, E88
All
M12x1.5x18
E90, E91, E92, E93
All
M12x1.5x18
E92 with S65
All
M10x1.5x15
Bracket, control arm, to
engine carrier
E46, E85, E86
All
M10x1.5x15
Rear axle carrier to frame
side member
E46
All
M12x1.5x18
E53
All
M14x1.5x21
E60, E61
All
M14x1.5x21
E63, E64
All
M14x1.5x21
E65, E66, E67
All
M14x1.5x21
E70, E71
All
M14x1.5x21
E83
All
M12x1.5x18
E85, E86
All
M12x1.5x18
E81, E82, E87, E88
All
M12x1.5x18
E90, E91, E92, E93
All
M12x1.5x18
Bearing block, trailing arm
to side member
E46, E83, E85, E86
All
M12x1.5x18
RA Notes on repairing threads
