1 Series 128i (N52K) Coupe
41 31 010
Replacing roof outer skin (version with
slide/tilt sunroof)
Read contents of Body, General.
Use only approved spot-welding apparatus for repairs.
Remove or cover those vehicle components in the repair area
which are susceptible to heat or dust.
For stripping and rigging operations, refer to texts on KSD
CD (FR number 41 31 010).
Following new body parts are required (refer to Electronic Parts
Catalogue ETK):
-
(1) Roof outer skin, slide/tilt sunroof
Release 4 screws (1) in roof channel.
Tightening torque 41 31 2AZ
.
RA Replacing roof outer skin (version with slide/tilt sunroof)
BMW AG - TIS
17.01.2013 18:13
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
