1 Series 128i (N52K) Coupe
51 47 161
Removing and installing/replacing right
luggage compartment wheel arch trim
Necessary preliminary tasks:
•
Remove trim on rear apron
Version with through-loading system:
•
Fold down backrest for right rear seat
Lever out socket (1) in direction of arrow and disconnect plug
connection.
Installation:
Guide (1) and catches (2) on socket (3) must not be damaged.
Release expansion rivets (1).
Release screw (2) and remove trim (3).
Pull out luggage compartment wheel arch trim (4) in inwards
direction.
RA Removing and installing/replacing right luggage compartment wheel arch trim
