1 Series 128i (N52K) Coupe
32 00 Steering
Type
Thread
Tightening specification
Measure
1AZ Steering gear to front axle carrier
E81, E82, E87,
E88, E90, E91,
E92, E93
M10
Replace screws & nuts
Jointing torque
56 Nm
Torque angle
90
°
2AZ Heat shield to steering gear
E81, E82, E87,
E88, E90, E91,
E92, E93
M6
7.6 Nm
3AZ Water drain valve to electric steering
gear (EPS)
E81, E82, E87,
E88, E90, E91,
E92, E93
Replace O-ring
20 Nm
4AZ EH converter to power steering gear
E92 / S65
3 Nm
AZD Steering
