1 Series E87 120d (N47) 5-door
25 11 235
Replacing bearing bushes for shift arm
Necessary preliminary tasks:
•
Remove shift arm
-
Press out bearing bush (1).
-
Coat new bearing bush with Circolight (sourcing reference:
BMW Parts Service).
-
Then press into shift arm until side surface of bush protrudes
uniformly.
Note:
Illustration shows: shift arm simply supported.
RA Replacing bearing bushes for shift arm
