1 Series E87 120d (N47) 5-door
Special tool can only be used on housing (1) of gas spring strut
(thick part).
Note:
Gas spring strut can also be installed the other way round
(housing on hood/bonnet).
Special tool can be used in both directions.
Release gas spring strut on left/right housing side.
Slide special tool (1) over housing (2) of gas spring strut.
Clip ball socket of special tool on ball stud.
Proceed in same way on other side.
RA Service position of engine hood/bonnet
