1 Series E87 120i (N46) 5-door
11 12 719
Grinding cylinder head lower face (N42 / N46)
(cylinder head dismantled)
Check evenness of cylinder head sealing surface with a standard
straight-edge (1).
Note:
Maximum plane deviation: longitudinal 0.10 mm.
Note:
Maximum plane deviation: transversal 0.05 mm.
Check measurement (A) before machining the cylinder head.
Original measurement and machining limit.
RA Grinding cylinder head lower face (N42 / N46)
