1 Series E87 120i (N46) 5-door
11 31 025
Removing and installing/replacing inlet
camshaft (N42/N46)
Special tools required:
•
11 9 291
•
11 9 292
•
11 9 293
•
11 9 301
•
11 9 302
•
11 9 303
•
11 9 310
•
11 9 320
•
11 9 390
Necessary preliminary tasks:
•
Remove ignition coils.
•
Remove spark plugs.
•
Remove cylinder head.
•
Remove inlet and exhaust adjustment unit.
Press locks on plug (1) and detach from pulse generator of inlet
camshaft.
Installation:
Lock on plug (1) must snap audibly into place.
