1 Series E87 120i (N46) 5-door
61 31 208
Removing and installing/replacing switch for
front lumbar support
Necessary preliminary tasks:
•
Remove outer cover on front seat
Expand catches (1) of cover (2), unclip switch for front lumbar
support (3) in direction of arrow and remove.
RA Removing and installing/replacing switch for front lumbar support
