1 Series E87 123d (N47S) 5-door
Detach plug (1) from reversing light switch.
Release cable from retainers.
-
Remove propeller shaft from transmission.
-
Release centre bearing.
-
Tie propeller shaft to one side.
Tasks are described in Removing propeller shaft.
Note:
When removing and installing the transmission, support the front
end of the engine at the housing with an installation aid
(e.g. transmission lifter).
Release screws (1).
Tightening torque 23 00 1AZ
.
Illustration similar
Supporting transmission:
Support with special tools 23 4 050 , 23 0 132 and 00 2 030 .
Secure transmission with tensioning strap (1).
Tasks are described in Transmission bracket.
After completion of work, check transmission oil level.
RA Removing and installing transmission (GS6-37DZ) N47, N47S
