1 Series 120i (N43) Convertible
51 37 000
Removing and installing/replacing complete
rear left or right power window unit
Warning!
Risk of injury!
Power window unit has no anti-trapping mechanism.
Necessary preliminary tasks:
•
Remove lower section of side trim at rear
•
Remove outer window cavity cover strip
•
Remove inner window cavity cover strip
Release screws (1).
Tightening torque 51 37 4AZ
.
Release or feed out cable holders (2) and remove connecting
bracket (3) towards top.
Release screw (1).
Tightening torque 51 37 3AZ
.
RA Removing and installing/replacing complete rear left or right power window unit
BMW AG - TIS
15.01.2013 19:35
Issue status (12/2007) Valid only until next DVD is issued
