1 Series 125i (N52K) Convertible
CBS reset with diagnosis system
•
The CBS jobs can be reset via the diagnosis system on the following path:
=> Diagnosis
=> Function selection
=> Service functions
=> Maintenance
=> CBS reset
•
The individual CBS items are displayed in the BMW diagnosis system with service counter and availability.
•
The service counter is increased by 1 during the reset. All service counters are set to "1" on new vehicles.
•
Availability is set to 100 % during the reset. It is basically a display quantity indicating the wear level of the job.
The greater the availability, the more distant is the next service appointment. 0 % means that the service item
must be carried out.
Important:
•
To be able to check and/or correct the car's on-board date properly, the diagnosis system requires the correctly set
tester system date!
•
The jobs may only be reset after the service measure has been completed.
•
The brake pads can only be reset with a new brake pad wear sensor.
