1 Series 125i (N52K) Convertible
51 16 000
Removing and installing or replacing mirror
on left or right front door
Necessary preliminary tasks:
•
Remove inner corner trim
Note:
On version with speaker, corner trim can remain hanging over
door trim panel.
Important!
Risk of damage!
Secure mirror against falling down.
Disconnect plug connection (1).
Fold seal (2) to one side slightly and release screws (3).
Tightening torque 51 16 1AZ
.
Installation:
Rubber grommet for plug connection (1) must be correctly seated
on door.
Seal (2) must be correctly seated on door trim panel and door.
Remove mirror (1) outwards.
Installation:
Check function.
RA Removing and installing or replacing mirror on left or right front door
BMW AG - TIS
17.01.2013 11:49
Issue status (12/2007) Valid only until next DVD is issued
