1 Series 125i (N52K) Convertible
E92 only:
Unhook seat covers on left and right.
Unclip ball socket (1) from ball head on left and right.
Installation:
Ball socket (1) must snap audibly into place.
Ball socket (1) must be able to move freely on ball head.
Unclip guide (2) for Bowden cable with plastic wedge.
Unhook seat covers (1) on left and right.
Release screws (2) on left and right.
Tightening torque 52 10 02AZ
.
Remove backrest frame (3) completely towards top.
Replacement:
-
Remove backrest cover with padding.
RA Removing and installing/replacing backrest frame on left or right front seat
