3 Series E30 324td (M21) TOUR
- a
0,20 mm
Thickness of shim (X)
3,90 mm
If C nominal is greater than C actual, "a" is subtracted from
thickness of shim (X).
Example II:
C
11,50 mm
e -
0,10 mm
C nominal
11,40 mm
Y measured on dial gage
2,20 mm
+ master disc thickness
9,50 mm
C actual
11,70 mm
C nominal
11,70 mm
RA Replacing input bevel gear and crown wheel (Type M) - final drive housing remove
