3 Series E30 M3 (S14) SAL
11 21 Crankshaft and Bearings S14
Ground sizes of main bearing journals
Twin classification
Standard red
mm
55.00
-0.010
-0.020
Standard blue
mm
55.00
-0.020
-0.029
Undersize 1 0.25 mm (0.010) red
mm
54.75
-0.010
-0.020
Undersize 1 0.25 mm (0.010) blue
mm
54.75
-0.020
-0.029
Undersize 2 0.50 mm (0.020) red
mm
54.50
-0.010
-0.020
Undersize 2 0.50 (0.020) blue
mm
54.50
-0.020
-0.029
Undersize 3 0.75 mm (0.030) red
mm
54.25
-0.010
-0.020
Undersize 3 0.75 mm (0.030) blue
mm
54.25
-0.020
-0.029
Radial crankshaft bearing play
mm
0.03 ... 0.07
