3 Series E30 M3 (S14) SAL
11 24 Connecting Rods and Bearings S14
∅
Large connecting rod eye
red
mm
52.000 ... 52.008
blue
mm
52.009 ... 52.016
Conrod bush inside dia.
mm
22.020 ... 22.024
Permitted deviation in weight of
connecting rods (without bearing shells)
g
±
4
TD Connecting Rods and Bearings, S14
