3 Series E36 316g (M43) COMP
51 43 000
Removing and installing or replacing rear left
or right side trim panel (compact)
Removing back-rest side section,
refer to 52 20 075
Open door and lower side window.
Partially loosen edge protection on B-pillar and side window.
Unclip and pull side trim panel out in upwards direction.
Installation:
If necessary, replace damaged clips.
Only replace:
Insert clips in new side trim panel.
RA Removing and installing or replacing rear left or right side trim panel (compact
