3 Series E36 316i (M43) COUPE
Installation:
Clean seal residue from sealing surfaces.
Coat contact surfaces of joint with Drei Bond 1209 (refer
to BMW Parts Service).
Installation:
Clean seal residue from sealing surfaces.
Apply a thin, uniform bead of Drei Bond 1209 sealing agent
(refer to BMW Parts Service) to transition area of half-moon
sections.
Installation:
When installing cylinder head cover, make sure that cylinder
head cover seal is correctly seated on rear side of cylinder
head.
Installation:
Install cover bolts and align cylinder head cover.
Hand-tighten all cover bolts without preload. Tighten cap screws
crosswise from inside to outside.
Tightening Torque,
refer to Technical Data 11 12 11AZ.
RA Removing and installing, sealing cylinder head cover (M43 / M43TU)
