3 Series E36 316i (M43) COUPE
C
9.02 mm
e -
0.10 mm
C nominal
8.92 mm
Y measured on dial gauge
2.12 mm
+ master disc thickness
7.00 mm
C actual
9.12 mm
C nominal
9.12 mm
C actual
- 8.92 mm
a
0.20 mm
master disc A
3.90 mm
- a
0.20 mm
Thickness of shim (X)
4.10 mm
If C nominal is less than C actual, "a" on the shim ring (x) is
added to the value.
The permitted tolerance for dimension (x) is derived from the
gauge steps available for shim rings (0.01 ... 0.03 mm).
