33 32 551

Replacing one rubber mount in the semi-
trailing arm (semi-trailing arm removed)

Measure and note protrusion (A) of old rubber mount.

Pull out rubber mount with special tools 33 3 331/332/333.

Pull in new rubber mount (1) as far as the previously measured
protrusion (A) using special tools 33 3 332/333/334.

RA  Replacing one rubber mount in the semi-trailing arm (semi-trailing arm removed)

BMW AG - TIS

19.01.2013  14:16

Issue status (12/2007) Valid only until next DVD is issued
