Alternatively
-
ABS control unit with additional software for Run Flat Indicator
> R56
The ABS control unit is standard equipment on the R56. RPA is integrated into the DSC control unit by means of
additional software.
Alternatively
-
ASC+T control unit with additional software for Run Flat Indicator
> R56
ASC+T is special equipment on the R56 (ASC+T: Automatic Stability Control plus Traction). RPA is integrated
into the ASC+T control unit by means of additional software.
Alternatively
-
DSC control unit with additional software for Run Flat Indicator
> E46, E53, E60, E61, E63, E64, E70, E83, E85, E86, E87, E90, E91, E92, E93
> R56: Optional equipment
With the DSC Mk60 and DSC 8, the RPA is integrated in the DSC control unit using additional software (The
E70 is equipped with DSC 8 Premium).
Alternatively
-
CIM: Chassis Integration Module
> E65, E66
The CIM controls:
•
Servotronic
•
Steering column adjustment
•
Run Flat Indicator (RPA)
The following control units are involved in the Run Flat Indicator system (in alphabetical order):
-
CAS: Car Access System
> E60, E61, E63, E64, E65, E66, E70, E87, E90, E91, E92, E93, R56
The CAS control unit provides input signals relating to terminal status
(e.g. terminal 15 ON).
-
GM: General module
> E46, E53, E83, E85, E86
The general module provides input signals relating to terminal status
(e.g. terminal 15 ON).
-
JBE: Junction box electronics
> E70, E87, E90, E91, E92, E93, R56
The JBE is the data interface (= gateway) between the K-CAN and the PT-CAN. (K-CAN stands for "Body
Controller Area Network"; PT-CAN stands for "Powertrain Controller Area Network")
The junction box consists of the junction box electronics and the electrical distribution centre.
-
KGM: Body gateway module
> E60, E61, E63, E64 from 09/2005
The body gateway module (KGM) replaces the safety and gateway module (SGM).
The KGM forms the data interface (= gateway) between the K-CAN and the PT-CAN.
-
M-ASK or CHAMP or CCC: Multi-audio system controller or multimedia platform or Car Communication
SBT Run Flat Indicator All models
