3 Series E36 318i (M42) CONVER
31 10 000
Removing and installing complete front axle
Caution!
After installation, align front axle
and fill power steering system.
Recycling:
Observe country-specific waste-disposal regulations.
Draw hydraulic fluid out of container - cannot be re-used - and
unfasten return line on container.
Unscrew pressure pipe on steering gear.
Remove steering spindle from steering gear,
refer to 32 31 070.
Airbag - remove steering wheel,
refer to 32 33 000.
Remove left and right brake caliper - lines remain connected - and
tie up against body,
refer to 34 11 519.
Disconnecting ABS impulse sensor line,
refer to Gr. 61 12 515.
Stabilizer connection on spring strut:
Unscrew left and right nuts and hold supports on spring struts with
adhesive tape.
Installation:
Wrench surface (1) on ball head must be parallel to spring-
strut axis. Replace self-locking nuts. Tightening Torque,
refer to Technical Data 31 35 7AZ.
RA Removing and installing complete front axle
