3 Series E36 318i (M43) TOUR
51 34 171
Replacing rear left or right door window
Removing rear door trim panel,
refer to 51 42 000
Removing finisher from window frame on rear door,
refer to 51 34 420
Remove acoustic insulation.
Installation:
If necessary, cement butylene thread (1) (Sourcing Reference
BMW Parts Service) to detached areas.
Pull inner recess cover off in upwards direction.
Remove clips (1).
RA Replacing rear left or right door window
