3 Series E36 318i (M44) SAL
Remove final drive.
Secure final drive with special tool 33 1 010 / 33 1 070 to
assembly stand.
Lift out retaining plate.
Mark position of nut (1) to drive shaft with a center punch.
Brace drive flange with special tool 23 0 020 and release nut.
Detach drive flange; if necessary, use special tool 33 1 150 .
Important!
Replace drive flange if sealing face is heavily worn.
RA Replacing shaft seal for drive flange on final drive
