3 Series E36 318is (M42) SAL
Removing drive belt (M42)
Loosen bolt (1).
Loosen nuts on bolts (2 and 3) and turn bolt (3) in direction of
arrow to slacken drive belt.
Take off drive belt.
Installation:
Adjust Vee-belt tension with special tool 11 5 020 by
rotating screw (3) in direction of arrow.
Tighten nut on bolt (3).
Tighten bolts (1 and 2).
RA Removing drive belt (M42)
