3 Series E36 318is (M42) SAL
11 00 050
Removing and installing engine (M42)
Note instructions on disconnecting and connecting the
battery,
refer to General Information MG12
Disconnect battery negative pole.
Move engine hood into assembly position; this work is described
for replacing windshield washer arms,
refer to 61 61 100
Unscrew and remove splash guard.
Removing transmission,
refer to 23 00 022 / 24 00 25
Drain coolant from engine block.
Installation:
Replace seal.
Tightening torque,
refer to Technical Data 11 11 5AZ
Removing fan cowl and radiator,
refer to 17 11 000
Removing intake filter housing,
refer to 13 71 000
RA Removing and installing engine (M42)
