3 Series E36 320i (M52) CONVER
11 25 Pistons with Rings and Pins M52 B 25
1st groove
End clearance
mm
0.1 ... 0.3
Axial play
mm
0.020 ... 0.060
2nd groove
End clearance
mm
0.2 ... 0.4
Axial play
mm
0.030 ... 0.065
3rd groove (oil scraper ring with spring loaded oil ring)
End clearance
mm
0.25 ... 0.5
Axial play
mm
0.020 ... 0.060
TD Pistons with Rings and Pins, M52, B 25
