3 Series E36 323i (M52) COUPE
11 00 Engine in General M52 B 20
Cylinder
6
Bore
mm
80
Stroke
mm
66
Effective displacement
cm
3
1991
Compression ratio
:1
11.0
Power
kW at
rpm
110/5900
Max. top speed
rpm
6500
Max. torque
Nm
rpm
190/4200
Compression pressure (approx. equal value for all
cylinders)
min. bar
10 ...11
TD Engine in General, M52, B 20
BMW AG - TIS
08.02.2013 18:19
Issue status (12/2007) Valid only until next DVD is issued
