3 Series E36 325i (M50) CONVER
Removing vibration-damper hub (M50
VANOS)
Hold flywheel with Special Tool 11 2 170.
Unscrew central bolt.
Take off washer and hub.
Installation:
Position hub in such a way that groove and woodruff key are
aligned.
Collar of washer faces hub.
Central bolt tightening torque,
refer to Technical Data
RA Removing vibration-damper hub (M50 VANOS)
