3 Series E36 325i (M50) CONVER
Version with plate spring
Fit approx. 4 mm thickness of thrust washer (1) to the intake
camshaft.
Version with plate spring
Install nuts and tighten down.
Tightening Torque,
refer to Technical Data 11 31 11AZ
Version without plate spring
Fit thrust washer (1) to the intake camshaft.
Version without plate spring
Tighten down thrust washer (1) with nuts.
Tightening Torque,
refer to Technical Data 11 31 11AZ
RA Replacing camshaft (M50 VANOS)
